Supertech VW / Audi 2.0T FSI/TSI Gen1, Gen2, Gen3 BEEHIVE Spring and Retainer Kit

Description

These images are representative, actual product images may differ. Beehive Valve Spring Kit for FSI/TSI/TFSI 2.0T engines (4-cylinder) BEEHIVE Spring Kit for 16V 2.0T engines (EA113, EA888.1, EA8882 and EA888.3). Latest revision from Supertech, with slightly less pressure than previous SPRK-A2416-BE2 kit. Beehive springs allow for the use of a smaller, lighter retainer allowing for higher RPM and more valve control. Seat Pressure: 91 @37.40 ; 105 @36 Open Pressure: 190 @ 10 ; 202@ 10 Max Lift: 11.00mm Coil Bind: 24.90mm Outer Spring ID: 12.70mm (top) Retainer: RET-A2416-N2 Kit Spring qty: 16 Kit Spring: SPR-A2416N-BE Rate: 9.8 Outer Spring OD: 24.00mm (bottom) Retainer qty: 16 Fitment for all EA113, EA888.1, EA888.2 and EA888.3 engines
